6
Introducing the Motherboard
LABEL COMPONENTS
2. CPU_FAN 4-pin CPU cooling fan connector
3. SYS_FAN 3-pin system cooling fan connector
4. DDR3_1~2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. F_USB1~2 Front panel USB 2.0 headers
7. F_PANEL Front panel switch/LED header
8. SATA1~4 Serial ATA 3.0 Gb/s connectors
9. CLR_CMOS Clear CMOS jumper
10. ME_UNLOCK ME unlock header-for factory use only
11. SPK Speaker header
12. PCIE1 PCI Express x1 slot
13. LPC_DEBUG LPC debug header-for factory use only
14. CASE CASE open header
15. F_AUDIO Front panel audio header
16. COM Onboard serial port header
17. ATX12V 4-pin +12V power connector
1. CPU Socket
LGA1155 socket for the latest Intel
®
Core
™
Family/
Pentium®/Celeron® processors
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
