Introducing the Motherboard
• LGA1155 socket for the latest Intel
®
Core
TM
Family/Pentium
®
/Celeron
®
processors
• Supports “Hyper-Threading” technology CPU
• DMI 5.0GT/s
CPU
Specifications
• AMI BIOS with 32Mb SPI Flash ROM
• Support Multi-language BIOS Utility
• Support ECS M.I.B III Utility
Form Factor • Mini-ITX Size, 170mm x 170mm
System BIOS
• Support eBLU*/eDLU/eSF* (*Warning: Microsoft .NET
Framework 3.5 is required)
AP support
• Intel
®
H61 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1600
*/1333/1066 DDR3 SDRAM
• 1 x PCI Express x1 slot
• Supported by Intel
®
H61 Express Chipset
-4 x Serial ATA 3.0 Gb/s devices
• VIA VT1705 6-Ch HD audio CODEC
• Compliant with HD audio specification
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 4 x USB 2.0 ports
• 1 x D-sub (VGA)
• 1 x DVI port (HDMI Port Optional)
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
Memory
Expansion Slots
Storage
LAN
Rear Panel I/O
Audio
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial ATA 3.0 Gb/s connectors
• 1 x COM header
• 1 x Case Open header
• 1 x ME_UNLOCK header
• 1 x Speaker header
• 1 x Clear CMOS header
• 1 x Front panel audio header
• 1 x Front panel switch/LED header
Internal I/O
Connectors &
Headers
• Realteck 8111E Gigabit LAN Fast Ethernet Controller
Realteck 8105E 10/100 LAN (Optional)
* The 3rd Generation CPU required.
