ECS H61H2-M12 User Manual

6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for new 2
nd
Generation Intel
嘐
Core
TM
i7/i5/i3
series processor/Intel
嘐
Pentium
嘐
Celeron
嘐
processors
2. CPU_FAN 4-pin CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SPI_DEBUG SPI debug header-for factory use only
6. SATA1~4 Serial ATA 3.0 Gb/s connectors
7. F_PANEL Front panel switch/LED header
8. F_USB1~2 Front panel USB 2.0 headers
9. CASE CASE open header
10. USBPWR_F1 Front Panel USB power select jumper
11. SPK Speaker header
12. LDC Debug card header
13. COM Onboard serial port header
14. ME_UNLOCK ME unlock header-for factory use only
15. SYS_FAN 3-pin system cooling fan connector
16. F_AUDIO Front panel audio header
17. CLR_CMOS Clear CMOS jumper
18. PCIE1~2 PCI Express x1 slot
19. PCIEX16 PCI Express slot for graphics interface
20. USBPWR_R1 Rear USB/PS2 power select jumper
21. ATX12V 4-pin +12V power connector
1. CPU Socket

ECS H61H2-M12 Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
CPU fan connector	Yes
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
On-board graphics card	-
Parallel processing technology support	Not supported
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	170 mm
Width	225 mm
