53
Using BIOS
Power Limit 2 Value (118)
Use this item to control Power Limit 2. PL2 provides an upper limit of the TDP
excursions. This is for Turbo mode.
Long Duration maintained (1)
Use this item to control the time window over PL1 value should be maintained. This
is for Turbo mode.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep
Technology).
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
1/2/3/4 Core Ratio (38/37/36/35)
These items show the Core Ratio limit value.
Press <Esc> to return to the Performance Tunning page.
Chipset Configuration
Scroll to this item to view the following screen:
Memory Multiplier Configuration
This item shows the information of Memory Multiplier Configuration.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Disabled/Enabled GT
OverClocking
Memory Multiplier Configuration
Memory Multiplier 10.67
Memory Timing Configuration
CAS# Latency (tCL) 7
Row Precharge Time (tRP) 7
RAS# to CAS# Delay (tRCD) 7
RAS# Active Time (tRAS) 20
Write Recovery Time (tWR) 8
Row Refresh Cycle Time (tRFC) 59
Write to Read Delay (tWTR) 4
Active to Active Delay (tRRD) 4
Read CAS# Precharge (tRTP) 4
Four Active Windows Delay (tFAW) 20
Intel Graphics Configuration
GT OverColocking Disabled
Memory Multiplier (10.67)
This item determines the operation of DDR SDRAM memory CAS(column address
strobe). It is recommanded that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
To Next Page
