54
Using BIOS
RAS# to CAS# Delay(tRD) (7)
This item specifies the RAS# to CAS# delay to Rd/Wr command to the same bank.
RAS# Active Time(tRAS) (20)
This item specifies the number of clock cycles taken between a bank active com-
mand and issuing the precharge command.
GT OverClocking (Disabled)
This item allows you to control the internal GFX Turbo mode. If the option is set to
Enabled, the following items will display.
Row Precharge Time(tRP) (7)
This item specifies Row precharge to Active or Auto-Refresh of the same bank.
Memory Timing Configuration
This item shows the information of Memory Timing Configuration.
CAS#Latency(tcl) (7)
This item determines the operation of DDR SDRAM memory CAS(column address
strobe). It is recommanded that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
Intel Graphics Configuration
This item shows the information of Intel Graphics Configuration.
Row Refresh Cycle Time(tRFC) (59)
Use this item to specify the Row Refresh Cycle Time of the same bank.
Write to Read Delay(tWTR) (4)
This item specifies the number of clock cycles that must occur between last valid
write operation and the next read command to the same internal bank.
Write Recovery Time(tWR) (8)
This item specifies the number of clock cycles taken between writing data and issuing
the precharge command.
Active to Active Delay(tRRD) (4)
This item specifies the minimum time interval between successive ACTIVE
commands to the different bank.
Read CAS# Precharge(tRTP) (4)
This item specifies internal read to precharge command delay time.
Four Active Windows Delay(tFAW) (20)
This item specifies completion time of four internal actions.
Graphics Current (Normal)
This item allows you to adjust the graphics current.
Graphics Core Ratio Limit (27)
This item shows the graphics core ratio limit value.
Graphics Voltage (Default)
This item shows the current Graphics voltage.
