ECS H61H2-M17 - Motherboard Introduction; Product Overview; Package Contents

Chapter 1
2
H61H2-M17 USER MANUAL
CPU
Specifications
• Intel
®
H61 ChipsetChipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600*/1333/1066/800 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 slots
(The PCI Express x16 slots conform to PCI Express 3.0*
Standard)
• 2 x PCI Express x1 Gen2 slots
• Supported by Intel
®
H61 Express Chipset
- 4 x Serial ATA 3Gb/s devices
Expansion
Slots
Storage
• 1 x PS2 keyboard & PS2 mouse connectors
• 1 x D-sub (VGA) port
• 1 x HDMI port (Optional)
• 1 x RJ45 LAN connector
• 6 x USB 2.0 ports (four USB 2.0 ports optional)
• Audio jacks for line-in, line-out and microphone
Rear Panel I/O
LAN • Atheros AR8152-B 10/100 LAN
• Atheros AR8151-B Gigabit LAN (Optional)
• VIA VT1705CE 6-Ch HD audio CODEC
- Compliant with HD audio specification
Audio
• LGA1155 socket for
2
nd
/3
rd
Generation Intel
®
Sandy/Ivy
Bridge Processors
• Supports “Hyper-Threading” technology CPU
Note: *For Ivy Bridge CPU only.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3Gb/s connectors
• 1 x Onboard Serial port header (COM)
• 1 x Case open header
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x Front Panel USB power select jumper
• 1 x Rear USB/PS2 power select jumper
• 1 x ME unlock header
• 1 x Speaker header
• 1 x Debug card header
Internal I/O
Connectors &
Headers
Note: Please go to ECS website for the latest CPU support list.
Please go to ECS website for the latest Memory support list.
Note: *For Ivy Bridge CPU only.
