H61H2-M4 USER MANUAL
2
Specifications
CPU
• Intel
®
H61 Chipset
Chipset
Memory
• 1 x PCI Express x16 Gen2 slot
• 1 x PCI Express x1 slot
• Supported by Intel
®
H61 Express Chipset
- 4 x Serial ATA 3Gb/s devices
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-Sub port (VGA)
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
• AtherosAR8161
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• AtherosAR8152 (Co-lay)
- 10/100 LAN Controller
- Wake-on-LAN and remote wake-up support
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3Gb/s connectors
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Clear CMOS jumper
Internal I/O
Connectors &
Headers
• VIA VT1705CF 6-Ch High Definiton Audio Codec
- Compliant with HD audio specification
Audio
LAN
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM
Note: Please go to ECS website for the latest Memory support list.
• LGA1155 socket for new 2
nd
/3
rd
Generation Intel
®
Core
TM
Family/ Pentium
®
/Celeron
®
Processors
