H61H2-M4 USER MANUAL
5
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
LGA1155 socket for new 2
nd
/3
rd
Generation Intel
®
Core
TM
Family/Pentium®/Celeron® Processors
2. ATX_POWER Standard 24-pin ATX power connector
3. DDR3_1~2 240-pin DDR3 Module slots
4. F_PANEL Front panel switch/LED header
5. PCIEX16 PCI Express slot for graphics interface
6. F_AUDIO Front panel audio header
7. PCIE PCI Express x1 slot
8. ATX12V1 4-pin +12V power connector
9. CPU_FAN 4-pin CPU cooling fan connector
10. SYS_FAN 3-pin system cooling fan connector
11. SATA1~4 Serial ATA 3Gb/s connectors
12. CLR_CMOS Clear CMOS jumper
13. F_USB1~2 Front panel USB 2.0 headers
