6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for latest new Core i7/i5/i3/
Pentium/Celeron processors
2. SCN For Mini PCIE1X card or mSATA card
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. SYS_FAN System cooling fan connector
5. CPU_FAN CPU cooling fan connector
6. ATX_POWER Standard 24-pin ATX power connector
7. PCIE16X PCI Express x16 graphics card slot
8. F_AUDIO Front audio header
9. ATX12V4P 4-pin +12V power connector
10. LPC_DEBUG LPC debug header
11. CLR_CMOS Clear CMOS jumper
12. CASE Chassis intrusion header
13. ME_UNLOCK ME unlock header
14. SATA1~2 Serial ATA 6.0Gb/s connectors
15. SATA3~4 Serial ATA 3.0Gb/s connectors
16. SPK Speaker header
17. F_PANEL Front panel switch/LED header
18. F_USB1~2 Front USB headers(F_USB1 supports Easy charger)
19. COM Onboard serial port header
1. CPU Socket
