4
Introducing the Motherboard
• Intel H67 Express Chipset
• LGA1155 socket for latest new Sandy Bridge Core i7/i5/i3/
Pentium/Celeron processors
• Supports “Hyper-Threading” technology CPU
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports DDR3 1333/1066 DDR3 SDRAM
• 1 x PCI Express Gen2 x16 slot
• 1 x Mini PCI Express slot
Chipset
Memory
Expansion
Slots
CPU
Specifications
• Supported by Intel H67 Express Chipset
• 2 x Serial ATA 6.0 Gb/s ports and 2 x Serial ATA 3.0 Gb/s
ports
Storage
• ALC892 8-CH High definition audio CODEC
• Realtek RTL8111E 10/100/1000 Fast Ethernet Controller or
RTL8105E 10/100 Fast Ethernet Controller (optional)
• 1 x SPDIFO port
• 1 x Bluetooth
• 1 x VGA port
• 1 x HDMI port
• 1 x DVI port
• 6 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x eSATA port
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in and 8-ch line out)
Audio
LAN
Rear Panel I/O
• 1 x 24-pin ATX Power Supply connector
• 2 x Serial ATA 6.0 Gb/s connectors and 2 x Serial ATA 3.0
Gb/s connectors
• 2 x USB 2.0 headers support additional 4 USB ports
• 1 x Chassis Intrusion header
• 1 x Front panel header
• 1 x Speaker header
• 1 x Front audio header
• CPU_FAN/SYS_FAN connectors
• 1 x Clear CMOS header
Internal I/O
Connectors &
Headers
• AMI BIOS with 32Mb SPI ROM
• Supports Plug and Play, STR/STD, Hardware moniter, DMI
• F7 hot key for boot up devices option
• CPU voltage adjustable
• Memory voltage adjustable
System BIOS
Form Factor
• Mini-ITX Size, 170 mm x 170 mm
