ECS H67H2-1 User Manual

36
Using BIOS
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Configuration
SATA Mode [IDE Mode]
Serial-ATA Controller 0 [Compatible]
Serial-ATA Controller 1 [Enhanced]
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
eSATA Not Present
mSATA Not Present
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
+/- : Change Opt.


:Select Screen
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Enter : Select
(1) IDE Mode. (2) AHCI Mode.
(3) RAID Mode.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Serial-ATA Controller 0/1 (Compatible/Enhanced)
Use this item to select the Serial-ATA cotroller options: Disabled, Compatible, En-
hanced.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Port 1~4 (Not present)
These items show the device installed of SATA Port 1~4.
Press <Esc> to return to the Advanced Menu page.
eSATA (Not present)
This item shows the eSATA device status of this channel.
mSATA (Not present)
This item shows the mini SATA device status of this channel.
