Installing the Motherboard
A
TX12V
:
A
TX 12V Power Connector
A
TX_POWER:
A
TX 24-pin Power Connector
Pin Signal Name Pin Signal Name
1
+3.3V
13
+3.3V
2
+3.3V
14
-12V
3
Ground
15
Ground
4
+5V
16
PS_ON
5
Ground
17
Ground
6
+5V
18
Ground
7
Ground
19
Ground
8
PWRGD
20
-5V
9
+5VSB
2
1
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
+3.3V
24
Ground
Pin Signal Name
4
Ground
3
Ground
2
Ground
1
Ground
Pin Signal Name
5
+12V
6
+12V
7
+12V
8
+12V
29
31
