ECS H67H2-M User Manual

31
Using BIOS
Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc.
ECS eJIFFY Function (Disabled)
This item enables or disables ECS eJIFFY Function.
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paeameters for critical voltages, temperatures and fan speeds.
Press <Esc> to return to the Advanced Menu page.
Make sure that the eJIFFY has
been installed to hard disk.

ECS eJIFFY Function
ECS eJIFFY Function [Disabled]
+/- : Value
Enter : Select

Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
:Select Screen
:Select Item
F1:General Help
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
ECS eJIFFY Function
Scroll to this item and press <Enter> to view the following screen:
-=- PECI Mode -=-
Offset to TCC Activation Temp : -27
+/- : Value
Enter : Select


:Select Item
F1:General Help
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
System Temperature : 31°C
CPU Fan Speed : 761 RPM
System Fan Speed : 5532 RPM
CPU Vcore : 0.984V
IMC Voltage : 1.056V
VDIMM : 1.260V
PCH Voltage : 1.044V
Smart Fan Function

Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
ESC:Exit
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
-=- PECI Mode -=-
Offset to TCC Activation Temp : -43
Main Advanced Chipset M.I.B III Boot Security Save & Exit
