ECS H67H2-M User Manual

46
Using BIOS
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intellient BIOS III) Menu
ICC Over-Clocking Lib Version (7.0.0.29)
This item shows the ICC over-clocking lib version.
Number of ICC Profiles (N/A)
This item shows number of ICC profiles.
M.I.B III (MB Intellient BIOS III)
Integrated Clock Chip Configuration
Performance Tuning
Auto Detect DIMM/PCI Clk [Enabled]
Spread Spectrum [Enabled]
CPU Voltage [Disabled]
DIMM Voltage [Disabled]
IMC Voltage [Disabled]
Intel(R) Core(TM) i5-2400 CPU @ 3.10GHz
Processor Speed 1600 MHz
Total Memory 2048 MB (DDR3 1333)
CPU Current Voltage 0.984V
Graphic Voltage 0.456V
VDIMM 1.260V
IMC 1.056V
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
+/- : Value


:Select Screen
:Select Item
F1:General Help
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Enter : Select
Integrated Clock Chip
Parameters


Integrated Clock Chip Configuration
Scroll to this item to view the following screen:
+/- : Value
Enter : Select


:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Integrated Clock Chip
Enabled/Disabled.
Integrated Clock Chip Configuration
ICC OverClocking Lib Version 7. 0. 0. 29
Number of ICC Profiles : N/A
Current ICC Profile Index : N/A
ICC Enable [Disabled]
Main Advanced Chipset M.I.B III Boot Security Save & Exit
