33
Using BIOS
• System Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Vcore
• IMC Voltage
• VDIMM
• PCH Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health
events, such as System & CPU temperature, CPU & DIMM voltage, CPU &
system fan speed,... etc.
Press <Esc> to return to the Advanced Menu page.
Power Management Setup
This page sets up some parameters for system power management operation.
Resume By PCI/PCI-E/Lan PME (Disabled)
The system can be turned off with a software command. If you enable this item, the
system can automatically resume if there is an incoming call on the PCI Modem or
PCI LAN card. You must use an ATX power supply in order to use this feature. Use
this item to do wake-up action if inserting the PCI card.
Resume By USB (S3) (Disabled)
This item allows you to enable/disable the USB device wakeup function from S3
mode.
+/- : Value
Enter : Select
:Select Screen
:Select Item
Power Management Setup
Resume by PCI/PCI-E/Lan PME [Disabled]
Resume by USB (S3) [Disabled]
EUP Function [Enabled]
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
About Resume by PCI/PCI-E/Lan
PME
EUP Support (Enabled)
This item allows user to enable or disable EUP support.
Press <Esc> to return to the Advanced Menu page.
