ECS HDC-I User Manual

4
Introducing the Motherboard
• Onboard AMD FT1 Processor
• VT1708B
• AR8151 Gigalan (Co-lay 10/100 AR8152)
• One SPDIFO port
• One Bluetooth
• One DVI port
• One VGA port
• SIX USB 2.0 ports and two USB 3.0 ports
• One LAN port
• One eSATA port
• One HDMI port
• Audio jacks for microphone, line-in and line-out
• 1 x 24-pin ATX Power Supply connector
• 4 x Serial ATA 6.0 Gb/s connectors
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• 1 x Clear CMOS header
• 1 x Front panel header
• 1 x Front panel audio header
• CPU FAN/SYS FAN connectors
• 1 x Speaker header
• 1 x CASE Open header
• 1 x LVDS header (Optional)
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 16Mb SPI Flash ROM
• Supports Plug and Play, ACPI & DMI, S1/STR(S3)/STD(S4),
Hardware monitor, Over-Clocking, Dual Dispaly
• Audio, LAN, can be disabled in BIOS
• F11 hot key for boot up devices option
System BIOS
Form Factor • Mini-ITX Size, 170mm x 170mm
CPU
Specifications
• AMD Hudson M1 chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports DDR3 1066/800 DDR3 SDRAM
• 1 x PCI Express X16 slot (running at x4 mode)
• 1 x Mini PCI Express X1 slot (with optional wireless card)
• Supported by AMD Hudson M1 chipset
• 4 x Serial ATA 6.0 Gb/s devices
Chipset
Memory
Expansion
Slots
Storage
