4. Then the default value of the item “Onboard LAN Boot ROM” changed to
“Enabled”.
Press <Esc> to return to the main menu setting page.
CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc.
Integrated Peripherals
Help Item
Options
Disabled
Enabled
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help

5. And the default value of the item “1st Boot Device” changed to “Realtek Boot
Agent” (LAN Boot First) automatically. It is convenient for users to boot from
LAN or handle when there is no disk.
CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc.
Advanced Setup
For the processor its CPUID
belows 0F41h.
TM2 only can be enable un-
der below setting.
1. Freq.>=3.6GHz FSB800
2. Freq.>=2.8GHz FSB533
Help Item
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimzed Defaults
F1:General Help

SATA Configuration IDE
Onboard SATA Mode Enhanced
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Enabled
Serial Port1 Address 3F8/IRQ4
USB Functions Enabled
Legacy USB Support Enabled
Thermal Management Enabled
TM Status TM1/TM2
Limit CPUID MaxVal Disabled
Enhanced Halt (C1E) Enabled
Intel XD Bit Disabled
Intel VT Enabled
Intel EIST Enabled
Intel (R) HT Technology Enabled
Intel (R) TurboMode tech Disabled
Quick Power on Self Test Enabled
Boot Up Numlock Status On
APIC Mode Enabled
1st Boot Device Realtek Boot Agent
2nd Boot Device CD/DVD
3rd Boot Device Removable Dev.
Hard Disk Drive Press Enter
Boot Other Device Yes
ECS eJIFFY Function Disabled
