ECS IC55H-A - Specifications

4
Introducing the Motherboard
• Intel H55 Express Chipset
• LGA1156 socket for latest Intel
®
Core
TM
i7/Core
TM
i5/Core
TM
i3 processors
• Supports “Hyper-Threading” technology CPU
• DMI 2.5 GT/S
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1800 (OC)/1600/1333/1066 DDR3 SDRAM
• 1 x PCI Express Gen2 x16 slot
• 3 x PCI Express x1 slots
• 2 x PCI slots
• Supported by Intel H55 Express Chipset
• 6 x Serial ATA 3.0 Gb/s Host Controllers
• ALC662 6-CH High definition audio CODEC
• Realtek 8111E Gigabit Fast Ethernet Controller
• 1 x PS/2 keyboard connector
• 1 x PS/2 mouse connector
• 1 x COM port
• 8 x USB ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in and line out)
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX12V connector
• 1 x CPU_FAN connector
• 1 x SYS_FAN connector
• 1 x PWR_FAN connector
• 6 x Serial ATA connectors
• 2 x USB 2.0 headers support additional 4 USB ports
• 1 x Chassis detect header
• 1 x Front panel header
• 1 x SPDIF out header
• 1 x ME unlock header
• 1 x Front panel audio header
• 1 x Speaker header
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 16Mb SPI ROM
• Supports Plug and Play, STR/STD, Hardware moniter, DMI
• F11 hot key for boot up devices option
• CPU voltage adjustable
• Memory voltage adjustable
• Support PgUp clear CMOS hotkey
System BIOS
Form Factor
• ATX Size, 305 mm x 190 mm
CPU
Specifications
