Mainboard User’s Manual
26
Load Optimal Settings
If you select this item and press Enter a dialog box appears. If you
press Y, and then Enter, the Setup Utility loads a set of fail-safe
default values. These default values are not very demanding and
they should allow your system to function with most kinds of
hardware and memory chips.
Load Best Performance Settings
If you select this item and press
Enter
a dialog box appears. If you
press Y, and then Enter, the Setup Utility loads a set of best-
performance default values. These default values are quite
demanding and your system might not function properly if you are
using slower memory chips or other low-performance components.
Features Setup Page
This page sets some of the parameters for peripheral devices
connected to the system.
OnBoard FDC Enabled
OnBoard Serial PortA 3F8h/COM1
OnBoard Serial PortB 2F8h/COM2
Serial Port2 Mode Normal
OnBoard Parallel Port 378h
Parallel Port Mode Normal
Parallel Port IRQ 7
Parallel Port DMA N/A
OnBoard Game Port 201h
OnBoard MIDI Port 300h
MIDI Port IRQ 10
OnBoard PCI IDE Both
OnBoard AC’97 Sound Enabled
OnBoard AC’97 Modem Enabled
USB Function Support Enabled
USB Function for DOS Disabled
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/ - : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
OnBoard FDC
Use this item to enable or disable the onboard
floppy disk drive interface.
OnBoard Serial
PortA/B
Use these items to enable or disable the onboard
COM1/2 serial port, and to assign a port address.
