Advanced Setup Page
Use this page to set more advanced information about your system.
Take some care with this page. Making changes can affect the
operation of your computer.
Trend ChipAway Virus Disabled
Quick Boot Enabled
1
st
Boot Device IDE-0
2
nd
Boot Device Floppy
3
rd
Boot Device CDROM
Try Other Boot Devices Yes
S.M.A.R.T. for Hard Disks Disabled
BootUp Num-Lock On
Floppy Drive Swap Disabled
Floppy Drive Seek Disabled
Password Check Setup
Boot To OS/2 > 64MB No
L1 Cache Enabled
L2 Cache Enabled
System BIOS Cacheable Enabled
Timing Setting Mode Normal
SDR/DDR CAS Latency SPD
Auto Detect DIMM/PCI Clk Disabled
Clk Gen Spread Spectrum Disabled
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
Trend ChipAway
Virus
This mainboard has built-in virus protection in the
BIOS. Use this item to enable or disable the built-in
virus protection. If the OS (like Windows 98SE
Japanese Version) needs to run EMM386.EXE and
this item is enable, please add the NOEMS
parameter (e.g.: EMM386 NOEMS) on it.
Quick Boot
If you enable this item, the system starts up more
quickly be elimination some of the power on test
routines.
1
st
Boot Device
2
nd
Boot Device
3
rd
Boot Device
Use these items to determine the device order the
computer uses to look for an operating system to
load at start-up time.
Try Other Boot
Device
If you enable this item, the system will also search
for other boot devices if it fails to find an operating
system from the first two locations.
S.M.A.R.T. for
Hard Disks
Enable this item if any IDE hard disks support the
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting
Technology) feature.
BootUp Num-
Lock
This items determines if the Num Lock key is active
or inactive at system start-up time.
To Next Page
