Hardware Monitor Page
This page sets some of the parameters for the hardware monitoring
function of this mainboard.
--- System Hardware ---
Vcore 2.000 V
Vcc2.5V 2.500 V
Vcc3.3V 3.300 V
Vcc5V 5.000 V
+12V 12.000 V
SB3V 3.300 V
-12V -12.000 V
SB5V 5.000 V
VBAT 3.300 V
System Fan Speed
CPU Fan Speed
System Temperature
CPU Temperature 30°C/86°F
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load Optimal values
F7 : Load Best performance values
Voltage
Measurements &
FAN Speeds
These items indicate cooling fan speeds in RPM
and the various system voltage measurements.
System / CPU
Temperature
These items display CPU and system temperature
measurement.
Change Password
If you highlight this item and press Enter, a dialog box appears
which lets you enter a Supervisor password. You can enter no more
than six letters or numbers. Press Enter after you have typed in the
password. A second dialog box asks you to retype the password for
confirmation. Press Enter after you have retyped it correctly. The
password is then required to access the Setup Utility or for that and
at start-up, depending on the setting of the Password Check item in
Advanced Setup.
