Phoenix – AwardBIOS CMOS Setup Utility
CPU & PCI Bridge Control
Item Help
PCI1 Master 0 WS Write [Enabled]
PCI2 Master 0 WS Write [Enabled]
PCI1 Post Write [Enabled]
PCI2 Post Write [Enabled]
PCI Delay Transaction [Disabled]
Menu Level
↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
PCI 1/2 Master 0 WS Write (Enabled)
When enabled, writes to the PCI bus are executed with zero wait states, pro-
viding faster data transfer.
PCI 1/2 Post Write (Enabled)
When enabled, writes from the CPU to PCU bus are buffered, to compensate
for the speed differences between the CPU and PCI bus. When disabled, the
writes are not buffered and the CPU must wait until the write is complete be-
fore starting another write cycle.
PCI Delay Transaction (Disabled)
The motherboard’s chipset has an embedded 32-bit post write buffer to sup-
port delay transactions cycles. Select Enabled to support compliance with PCI
specification version 2.1.
Press <Esc> to return to the Advanced Chipset Features screen.
Memory Hole (Disabled)
This item is used to reserve memory space for ISA expansion cards that re-
quire it.
System BIOS/Video RAM Cacheable (Disabled)
These items allow the video and system to be cached in memory for faster
execution. Leave these items at the default value for better performance.
VGA Share Memory Size (32M)
These items allows you to select the shared memory size for VGA usage.
Integrated Peripherals
These options display items that define the operation of peripheral compo-
39
