ECS NM70-I User Manual

Chapter 3
NM70-I USER MANUAL
47
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset Tweak Boot Security Exit
Windows 7 or other OS:
Boot policy for Legacy OS
Windows 8: Boot policy for
UEFI OS without
Compatibility Support
Module (CSM)
Manual: User customized
CSM parameters & Boot
policy
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Boot Configuration
Operation System Select Manual
Bootup NumLock State On
Quiet Boot Enabled
Boot mode select LEGACY
Set Boot Priority
Boot Option #1 Hard Disk
Boot Option #2 CD/DVD
Boot Option #3 USB/Floppy
Boot Option #4 USB CD/DVD
Boot Option #5 USB Hard Disk
Boot Option #6 USB Flash: Kingmax US...
Boot Option #7 Network
USB Key Drive BBS Priorities
CSM parameters
Boot Configuration
This item shows the information of the Boot Configuration.
Operation System Select (Manual)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Quiet Boot (Enabled)
This item enables or disables quiet boot.
Boot mode select (LEGACY)
Use this item to select boot mode.
Boot Op
tion #1/2/3/4/5/6/7
Use these items to set the system boot order.
