LABEL COMPONENTS
1. CPU Onboard Intel® Celeron ICP847/807 or other Processors
2. PCIEX16 PCI Express slot for Graphics Interface (runs at x8 mode)
3. SPDIFO SPDIF out header
4. F_AUDIO Front panel audio header
5. ME_UNLOCK ME unlock header-for factory use only
6. CASE Case open header
7. CLR_CMOS Clear CMOS jumper
8. SATA1 Serial ATA 6Gb/s connector
9. SATA2~4 Serial ATA 3Gb/s connectors
10. F_USB1~2 Front panel USB 2.0 headers
11. BZ Buzzer (optional)
12. ATX_POWER Standard 24-pin ATX power connector
13. LDC Debug card header
14. SYS_FAN 3-pin system cooling fan connector
15. CPU_FAN 3-pin CPU cooling fan connector
16. F_PANEL Front panel switch/LED header
17. COM2 Onboard serial port header
18. LPT Onboard parallel port header
19. SO_DIMM1 204-pin DDR3 SDRAM SO-DIMM
