Introducing the Motherboard

Table of Motherboard Components

This concludes Chapter 1. The next chapter explains how to install the motherboard.

1 CPU Socket LGA775 socket for Intel Core

2 Duo/

Pentium D/Pentium 4/Celeron D CPUs

2 CPUFAN CPU cooling fan connector

3 DIMM1~4 240-pin DDR2 SDRAM slots

11 IDEJ1 Primary IDE channel

9 SYSFAN System cooling fan connector

6 JP1 Clear CMOS jumper

10 SPK1 Speaker header

5 FDD1 Floppy diskette drive connector

17 PCI1~3 32-bit add-on card slots

7 SATA1/3/5/6/7 Serial ATA connectors

15 CD_IN1 Analog audio input connector

12 PANEL1 Front panel switch/LED header

14 AUDIO1 Front panel audio header

16 SPDIOF1 SPDIF out header

8 IR1 Infrared header

13 USB1-3 Front Panel USB headers

4 ATX1 Standard 24-pin ATX power connector

20 ATX4P1 Auxliary power connector for graphics card

19 PCIE1/PCIE3 PCI Express slot for graphics interface

18 PCIE2/PCIE4 PCI Express x1 slot

22 NBFAN Northbridge cooling fan connector

21 ATX12V1 Auxiliary 8-pin power connector

LABEL COMPONENT

Questions and Answers:

Need help?

Do you have a question about the ECS P965T-A and is the answer not in the manual?

ECS P965T-A Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA connectors	5
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Audio chip	Realtek ALC883
Certification	WHQL
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	-
On-board graphics card	No
Parallel processing technology support	Not supported
PCI Express x16 slots	2
Networking features	Gigabit Ethernet
BIOS type	Award
BIOS memory size	32 Mbit
