ECS Z170IU-C43 - Brief Introduction; Specifications

Z170IU-C43 USER MANUAL
1
Brief Introduction
CPU
Specifications
• Intel
®
Z170 Chipset
Chipset
• Dual-channel DDR4 memory architecture
• 2 x 288-pin DDR4 DIMM sockets support up to 32 GB
• Supports DDR4 2133/3000 MHz DDR4 SDRAM
Memory
• 1 x PCI Express x16 Gen3 slot
• Supported by Intel
®
Z170 Express Chipset
- 4 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 2 x USB 3.1 ports
• 1 x DVI port
• 1 x HDMI port
• 2 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x 8-CH Audio jack
• 1 x DP port
Rear Panel I/O
• Intel WGI 219V Lan
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• LGA1151 socket for the latest Generation Intel
®
Skylake Fam-
ily Processors
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 4 x Serial SATA 6Gb/s connectors
• 1 x TPM header
• 1 x Case open header
• 1 x Clear CMOS jumper
• 1 x Buzzer header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x FUSBEZC header supports additional two USB 2.0 ports
(Support EZ Charger)
Internal I/O
Connectors &
Headers
• Realtek ALC892
- 8 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
LAN
