ECS Z170IU-C43 - Header Pin Definition and Jumper Settings

Z170IU-C43 USER MANUAL

F_AUDIO
1
TPM
PORT 1L
PORT 1R
PORT 2R
SENSE_SEND
AUD_GND
PRESENCE#
SENSE1_RETURN
Key
SENSE2_RETURN
KEY
1
F_PANEL
Hard disk LED (-)
Hard disk LED (+)
Reset Switch (-)
Reset Switch (+)
Reserved
Power Switch (-)
Power Switch (+)
MSG LED (+)
MSG LED (-)
PORT 2L
4
BZ
1
Power +5V
Signal
Key
GND
1
LRESET#
SMBDATA
LFRAME#
LAD2
Key
Ground
Ground TPM_CLK
RESERVE1
VCC3
LAD3
LAD1
SERIRQ
Ground
SMBCLK
LPCPD#
Ground
3VSB
RESERVE0
LAD0
