ECS Z170IU-C43 User Manual

1
Intruder
GND
CASE
CLR_CMOS Jumper
FUSBEZC
1-2: NORMAL
Before clearing the CMOS, make sure to turn off the system.
CLR_CMOS
3
1
2
CPU_FAN & SYS_FAN
Sensor
PWM
System Ground
Power +12V
2-3: CLEAR CMOS
1
5
Z170IU-C43 USER MANUAL
Sensor
PWM
System Ground
Power +12V
1
USB3F
1
Front Panel USB Power
Front Panel USB Power
Ground
Ground
USB3 ICC Port1 D+
Not Connected
Ground
Ground
USB3 ICC Port1 D-
USB3 ICC Port2 D+
USB3 ICC Port2 D-
USB3 ICC Port1 SuperSpeed Rx-
USB3 ICC Port2 SuperSpeed Rx-
USB3 ICC Port1 SuperSpeed Rx+
USB3 ICC Port2 SuperSpeed Rx+
USB3 ICC Port1 SuperSpeed Tx-
USB3 ICC Port2 SuperSpeed Tx-
USB3 ICC Port1 SuperSpeed Tx+
USB3 ICC Port2 SuperSpeed Tx+
1
9
NC
KEY
Ground
Power +5V
Power +5V
Ground
USB Port A (-)
USB Port B (-)
USB Port A (+)
USB Port B (+)
