Chapter 3

Z97M-PK USER MANUAL

Smart Fan start PWM value (180)

Smart Fan start PWM TEMP (DTS) (45)

This item is used to set the start PWM value of the smart fan.

This item is used to set the start temperature of the smart fan.

DeltaT (3)

This item specifies the range that controls CPU temperature and keeps it from going

so high or so low when smart fan works.

Smart Fan Slope PWM value (10)

This item is used to set the Slope Select PWM of the smart fan.

This item is used to set the CPU fan/System fan full speed offset value.

CPU Fan/System Fan Full Speed Offset (DTS) (52)

Press <Esc> to return to the PC Health Status page.

• CPU Temperature (DTS)

• System Temperature

• CPU Fan Speed

• System Fan Speed

• Core Voltage

• DIMM Voltage

• +12V

• +5V

• +3.3V

System Component Characteristics

These items display the monitoring of the overall inboard hardware health events,

such as CPU & DIMM voltage, CPU & System fan speed...etc.

Press <Esc> to return to the Advanced Menu page.
