ECS Z97M-PK User Manual

Chapter 3
Z97M-PK USER MANUAL
58
 Over Voltage Configuration
Scroll to this item to view the following screen:
PCH Core Voltage 1.056 V (Auto)
This item allows you to adjust the PCH Core voltage.
DIMM Voltage 1.488 V (Auto)
This item allows you to adjust the DIMM voltage.
Processor Input Voltage (Auto)
This item allows you to adjust the processor input voltage.
Vdroop (Enabled)
Use this item to enable or disable the Vdroop.
Main Advanced Chipset M.I.B. III Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
PCH Core Voltage 1.056 V Auto
DIMM Voltage 1.500 V Auto
Processor Input Voltage Auto
Vdroop Enabled
CPU Adaptive Voltage Target(mV) 0
CPU Voltage Mode Adaptive
CPU Voltage Offset(mV) 0
Offset Preflx +
RING Adaptive Voltage Target(mV) 0
RINGVoltage Mode Adaptive
RING Voltage Offset(mV) 0
Offset Prefix +
SVID Control Enable Enabled
SVID Override Voltage Target(mV) 0
FIVR Faults Enable Enabled
FIVR Efficiency Enable Enabled
GT Adaptive Voltage
Target(mV) 0
GT Voltage Mode Adaptive
GT Voltage Offset (mV) 0
Offset Prefix -
UNCORE Voltage Offset (mV) 0
Offset Prefix +
IOA Voltage Offset (mV) 0
Offset Prefix +
IOD Voltage Offset (mV) 0
CPU/RING/GT Adaptive Voltage Target(mV) (0)
This item allows you to adjust the CPU/RING/GT Adaptive voltage target from 0 to
2000mV.
