Chapter 3
Z97M-PK USER MANUAL
59
CPU/RING/GT Voltage Mode (Adaptive)
This item allows you to set the CPU/RING/GT voltage mode.
CPU/RING/GT/UNCORE/IOA/IOD Voltage Offset(mV) (0)
This item allows you to adjust the CPU/RING/GT/UNCORE/IOA/IOD voltage offset from
-1000 to 998mV.
Offset Prefix (+)
This item allows you to select the offset value as positive (+) or negative (-).
SVID Control Enable (Enabled)
This item allows you to enable or disable the SVID control. If this function be
disabled, it will not be changed until CPU powers down.
SVID Override Voltage Target(mV) (0)
This item allows you to adjust the SVID override voltage target, up to 2500mV.
FIVR Faults Enable (Enabled)
This item allows you to enable or disable the FIVR faults. If this function is disabled,
it will not be changed until CPU powers down.
FIVR Efficiency Enable (Enabled)
This item allo
ws you to enable or disable the FIVR efficiency. If this function is
disabled, it will not be changed until CPU powers down.
Press <Esc> to return to the M.I.B. III Menu page.
Intel(R) Core(TM) i7-4765T CPU @ 2.00GHz
This is display-only field and displays the information of the CPU installed in your
computer.
Processor Speed (2000 MHz)
This item shows the CPU speed.
Memory Frequency (1333 MHz)
This item shows the memory frequency.
Total Memory (4096 MB (DDR3))
This item shows the total memory.
Spread Spectrum (Auto)
If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
