ECTIVE CSI 20 - Front View: CSI 30; Terminal for Direct Connection

40 ECTIVE CSI & SSI Series
Front view: CSI 30
1. Switch ECO/OFF/UPS
2. LED „Power“
3. LED „Fault“
4. LED „Charge“
5. LED „AC-In“
6. LED „By-Pass“
7. Remote control port
8. USB-port
9. Shore power
10. Protective earthing
11. 230 V power socket
Te r m i n a l f o r dir e c t c o n n e c t i o n
(CSI 30 and SSI-Series)
8
7
3
9
1
10
2
4
5
6
11
