EDAN M3 Service Manual

M3 Vital Signs Monitor Service Manual
- 8 -
This symbol indicates that the instrument is IEC/EN60601-1 Type BF equipment. The unit
displaying this symbol contains an F-Type isolated (floating) patient applied part providing a high
degree of protection against shock, and is suitable for use during defibrillation.
Figure1-6 Rear Panel of M3
Sockets on the rear panel are shown in Figure1-6,
① Equipotential grounding terminal for connection with the hospital’s grounding system.
② Power supply socket: AC100 ~ 240 V, 50/60 Hz.
③ Network Interface (reserved): Standard RJ45 Socket, for connecting to MFM-CMS of EDAN.
Bottom panel
There are battery compartment and fuse box at the bottom panel.
①
②
③

EDAN M3 Specifications

General

Brand	EDAN
Model	M3
Category	Monitor
Language	English
