EDAN M3 - Interface Icons and Meanings

M3 Vital Signs Monitor Service Manual
- 3 -
Figure1-3 Main display with data
The icons on the interface and their meanings are as follows:
Battery status indicator
Connected to mains power supply
Network connection indicator
Network connection off
Medium/Low alarm icon
High alarm icon
Audio system off icon
Audio alarm paused icon
Parameter alarm off
