MT-201 Trolley Installation Guide
or without handle
10
iSE link board
1
Applicable to iSE with
thermal printer
Accessories
A
B
C
D
E
F
G
H
I
J
K
L
No.
Name
Qty
(pcs)
Spares
(pcs)
Remarks
A
M5×14 screw
4
2
B
M3×10 cross recessed pan
head cap screw
4
2
Used for link
board—#2
major part
C
17# /19# normal open-end
spanner
1
-
-
D
Ф12 spring washer + plain
washer
5 sets
1 set
-
E
4mm hexagon spanner
1
-
-
F
M10×60 bolt
1
-
-
G
3mm hexagon spanner
1
-
-
H
Ф10 spring washer + plain
washer
1 set
1 set
-
I
M3×14 Cross recessed
countersunk head screw
1
-
Used for the
clamp
J
8mm hexagon spanner
1
-
-
K
M3×12 screw
4
2
Used for the
iSE link
board
L
M5×12 screw
4
2
Used to
fasten the
basket
