PA Series Biofeedback and Stimulation System User Manual Introduction
17
2.2.1 Sensor Cable
The sensor cable connects the sensor with the host to conduct signals.
2.2.2 Vagina Sensor
There are two types of vagina sensors, the reusable one and the disposable one.
The vagina sensor is used to conduct electrical signals between the pelvic floor muscles
and the host, including pelvic floor Surface Electromyography signal (SEMG) and
electrical stimulation signals.
Using methods:
1. Open the package and connect the vagina sensor to the host with the sensor
cable.
2. Insert the vagina sensor into the vagina till the end of the sensor. Select an
assessment protocol or treatment plan and start it.
3. After the assessment or treatment, disconnect the sensor from the cable. For
disposable vagina sensor, pull it out and dispose of it as medical waste. For
Name
Model
Specification
Area
Actual Area
Figure
Impedance
Pelvic
Floor
Intracavit
y Sensor
SV2
Intracavity
sensor,
which is
applied in
the vagina
and it is
reusable
no less
than
8cm
2
12.34 cm
2
length*width:57
mm*23.2 mm
Error ±5%
Pelvic
Floor
Intracavit
y Sensor
SV1
Intracavity
sensor,
which is
applied in
the vagina
and it is
disposable.
no less
than
8cm
2
12.34 cm
2
Irregular
length*width
57mm*23.2 mm
Error ±5%
Adhesive
Electrode
s
SK1
Adhesive
electrodes,
which are
applied on
the skin and
they are
disposable
no less
than
15cm
2
19.625cm
2
Diameter:5cm
Error±5%
<500Ω
±5%
Vagina
Stress
Probe
PV
Intracavity
stress
probe, which
is applied in
the vagina
and it is
reusable.
/
/
/
/
