SE-301 Series Electrocardiograph User Manual Technical Specifications
- 52 -
A1.2 Environment Specifications
Transport & Storage Working
Temperature: -20ºC (-4ºF) ~ +55ºC (+131ºF) +5ºC (+41ºF) ~ +40ºC (+104ºF)
Relative Humidity:
15%RH–95%RH
Non-Condensing
15%RH–95%RH
Non-Condensing
Atmospheric Pressure: 70kPa–106kPa 70kPa–106kPa
A1.3 Physical Specifications
Dimensions
224 mm×143 mm×54 mm, ±2 mm
Weight < 1kg (Excluding recorder paper and battery)
Display
800×480 LCD Screen
A1.4 Power Supply Specifications
Mains Supply:
Operating voltage =100V--240V~
Operating frequency = 50Hz / 60Hz
Power adapter output voltage: 19V, 2A
Built-in Lithium Battery Pack:
Rated voltage = 14.8V
Rated capacity = 2500mAh
When the battery is fully charged, the 3-channel
electrocardiograph can work normally about 8.5 hours. It
can continuously record about 5 hours in Manual mode, and
record at least 500 reports at most in the AUTO mode.
Necessary Charge time: ≤ 3.5 hours
Cycle life ≥ 300 times
