Edax Element - Basic System Cabling

Basic System Cabling
Element Basic User Guide
Page 18 of 21
5 BASIC SYSTEM CABLING
Figure 4 - Typical System Connections
EDAX PC
Dual Port NIC
(PCIe)
2735.171.31099
IP 192.168.0.101
IP ###.###.###.###
SYNC (panel)
5335.007.31700
SG-3 (PCIe)
5335.007.31400
DPP Box
4035.075.00990
IP 192.168.0.100
Ethernet cable 2435.072.44045R
Sync cable 4035.008.10900
Ferrite
5 V Power
Supply
2735.075.31149R
IEC 2435.072.44052R or
US 2435.072.44053R
SEM PC
IP ###.###.###.###
Microscope
5V Power
4035.008.11340
50 Ω BNC Signal
2735.171.30915
Element
Detector
USB Port
USB Cable 2735.171.31153
MAINS
Ethernet cable
Beam Control Interface cable – Microscope Model Dependent – 4035.008.#####
Monitor
MAINS
MAINS
USB Port
DVI
For
Touchscreen
For Column control
and/or Network
Ground Cable Kit 4035.075.00920
Cable 4035.008.11270
100-240V
100-240V
100-240V
Printer
(optional)
MAINS
100-240V
5V
J6
J4
