Edax Element - Boards Inside the PC

Troubleshooting
Element Basic User Guide
Page 21 of 21
6.3 BOARDS INSIDE THE PC
Figure 7 - Boards inside the analyzer (HP Z230)
SG-3 Board
Network Board
Sync Panel
Air Flow
Fan
Air Flow
Fan
Internal Sync cable
Power Supply
Hard Drive
