Edge-Core ECS4620-28F-2AC Cli Reference Guide

Chapter 9 | General Security Measures
Network Access (MAC Address Authentication)
– 323 –
◆ When used with 802.1X authentication, the intrusion-action must be set for
“guest-vlan” to be effective (see the dot1x intrusion-action command).
◆ A port can only be assigned to the guest VLAN in case of failed authentication,
if switchport mode is set to Hybrid.
Example
Console(config)#interface ethernet 1/1
Console(config-if)#network-access guest-vlan 25
Console(config-if)#
network-access
link-detection
Use this command to enable link detection for the selected port. Use the no form of
this command to restore the default.
Syntax
[no] network-access link-detection
Default Setting
Disabled
Command Mode
Interface Configuration
Example
Console(config)#interface ethernet 1/1
Console(config-if)#network-access link-detection
Console(config-if)#

Edge-Core ECS4620-28F-2AC Specifications

General

Model	ECS4620-28F-2AC
Ports	28
SFP Ports	24
Power over Ethernet (PoE)	No
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	L2/L3
MAC Address Table Size	16K
VLANs	4K
Weight	3.5 kg
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Type	Switch
10G SFP+ Ports	4
Power Supply	AC: 100~240VAC, 50/60 Hz
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1P, IEEE 802.1D, IEEE 802.1S, IEEE 802.1W
