7
5. Cut the side channel sealing strip into two equal lengths. Remove the protective backing
and apply it to the back of the side channel starting just below the window panel frame.
Remove any excess length so that the seal is even with the bottom of the side channel.
Remove the Front Panel
1. Remove the two (2) front retaining screws from the front frame.
2. Gently pull the front out and lift up to release it from the case.
3. Release the control board plug.
