SEASTAR and BAYSTAR Hydraulic Steering Systems
9-1
CHAPTER
9
HELMS
The SeaStar helm pump is the heart of the hydraulic steering system.
SeaStar helm pumps are the product of many years of research and
experience by the world's foremost builder of manual hydraulic steering
systems. Our efforts have resulted in a design which represents the
ultimate in efficiency, safety and reliability, yet is easy to install and
maintain. Superior design, teamed with the finest materials, precision
manufacturing and rigid quality control all add up to an outstanding
product which is certain to set industry standards for years to come.
Standard helm features
• Compact, stylish design.
• Available in 1.7, 2.0 and 2.4 cubic inch displacements.
• Convenient front of dash fill.
• Small 3.0" hole cutout on dash.
• Can be retrofitted into old SeaStar 4.5" hole cutout.
• Complete with elbow fittings.
Rear mount helm features (CONTACT YOUR LOCAL DISTRIBUTOR
FOR AVAILABILITY)
• Behind dash mounting configuration.
• Available in 1.4, 1.7 and 2.4 cubic inch displacements.
• Top of dash fill point.
• Complete with elbow fittings.
Sport Tilt helm features
• 5 wheel positions allow adjustment to most comfortable
steering position.
• 48 degree tilt range (12 down - 36 up).
• Available in 1.7, 2.0 and 2.4 cubic inch displacements.
• Remote fill point.
• Complete with elbow fittings.
• Comes with newly designed tilt mechanism.
Traditional Tilt helm features
• 5 wheel positions allow adjustment to most comfortable
steering position.
• 48 degree tilt range (18 down - 30 up).
• Available in 1.7, 2.0 and 2.4 cubic inch displacements.
• Convenient front of dash fill.
• Complete with elbow fittings.
