9-2
Selection Guide
1 Helm rotor supported by three roller bearings.
2 Ball bearing piston race.
3 Field replaceable shaft seal.
4 1/4" NPT ports.
5 Built-in lock valve for positive rudder lock.
6 Patented bleed tubes.
7 Internal air pocket eliminates oil expansion overflow.
8 Integral relief valve.
Features
Features of SeaStar Helm Pumps
HEAVY DUTY
SHAFT SEAL
AND WIPER
STAINLESS STEEL
SHAFT
Specifically designed to be used on
smaller fishing vessels involved in
the Lobster and Crabbing Industries.
The Commercial Helm Pumps are
designed with a stainless steel shaft
and heavy duty shaft seal and wiper.
This new shaft and seal help protect
the Helm Pump from the abrasive
effects of sediment that is brought
on board by the operator handling
Traps or Pots.
Commercial Helms
Part# HH5217, HH5224
NOTICE
For Commercial Use ONLY.
HELMS
To Next Page
