Edgewater Networks EdgeMarc 4500 Series User Manual

10
2
Getting Started
Physical Installation
The 4500 series is designed for desktop, rack or wall-mount installation. Observe the following
guidelines when installing the system:
• Always verify that the AC cord is disconnected from a power source prior to installation.
• Ensure that the installation site has adequate air circulation and meets the minimum
operating conditions for the system as specified in Specifications section of this document
Required Tools and Materials
• If the unit is to be mounted on the wall then:
─ 1 Flat or Philips screw driver
─ 2 round or flat head Philips or slotted screws – 1 ½ inch long
─ 2 hollow wall anchors
• If the unit will be mounted in a shelf:
─ 1 Flat or Philips screw driver
• If T1/E1 port will be used to connect to WAN
─ T1 cable to connect the T1/E1 port to a T1 line.
Warning
To reduce the risk of fire, use only 26 AWG or larger wire (e.g. 24, 22, 20, etc.) to
connect the T1 port on your unit to an RJ-45 jack.
• Ethernet cables to connect the LAN ports to LAN switches or to individual IP phones. They
can also be used to connect the Ethernet WAN port to a WAN router, a Cable Modem or a
DSL Modem, if T1/E1 port is not being used to connect to the WAN.
Desktop Installation
1. Remove the 4500 and accessories from the shipping container.
2. Place the 4500 on a flat, dry surface such as a desktop, shelf or tray.
