EDIFIER QD35 User Manual

22
English
21
English
Charge external devices
Input: 100-240V~ 50/60Hz 1A
USB-C port only (35W max.):
5V 3A, 9V 3A, 12V 2.91A, 15V 2.33A, 20V 1.75A
USB-A port only (18W max.):
5V 2.4A, 9V 2A, 12V 1.5A
USB-C port and USB-A port simultaneously:
18W max. + 18W max.
Note:
• During charging, make sure that the power cable is properly connected and the main power button on the rear panel of this
speaker is switched to "ON".
• If the charging current is 3A, use a charging cable that supports the charging current of 4.5A or higher for efficient charging.
Connect your device to the USB-C port or USB-A port on the left panel of this speaker for charging.
Power Output: Mid-Bass (25W) + Treble (15W)
Frequency Response:
60Hz-40kHz
Declaration for EU
Frequency Band: 2.402GHz ~ 2.480GHz
RF Power Output:
≤
10 dBm (EIRP)
There is no restriction of use.
Specifications

EDIFIER QD35 Specifications

General

Speaker type	2-way
Number of drivers	2
Speaker placement	Tabletop/bookshelf
Audio output channels	- channels
Mid-range driver diameter	76.2 mm
Number of mid-range drivers	1
Mid-range driver diameter (imperial)	3 \
Frequency range	60 - 40000 Hz
RMS rated power	40 W
Signal-to-Noise Ratio (SNR)	85 dB
Product color	White
Recommended usage	Universal
AUX in	Yes
Bluetooth version	5.3
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Power source type	USB

Weight and Dimensions

Depth	141.7 mm
Width	277.8 mm
Height	164.8 mm
Weight	2640 g
