EDILGRAPPA PR16 - List of Accessories Included in the Supply; Technical Features; Hydraulic, Mechanical and Electrical Specifications

PR16-32
7
Observe the warnings on the plates and stickers. Failure to do so could lead to
injury or death. Make sure the plates and stickers are attached and legible. If not,
apply them or request the maker for replacements.
0.03 LIST OF ACCESSORIES INCLUDED IN THE SUPPLY
• Case
• General safety rules, Use and maintenance instructions
• Declaration of conformity
• Warranty certificate
• Simple repair key, if appropriate
1 TECHNICAL FEATURES
1.01 HYDRAULIC, MECHANICAL AND ELECTRICAL SPECIFICATIONS
Maximum bending size and characteristics of material [ mm and
daN/mm² ]
Ø 32 mm / R = 75 daN/mm²
Maximum output force from rod [ t ]
21.1
Maximum operating pressure [ bar ]
550
Dimensions: Length X Width X Height [ mm ]
601 x 300 x 229
Bending angle
180° to 80° (depending on the
diameter and hardness of the
material)
Weight [ kg ]
24.4
Guaranteed no-load LwA sound level (CEI EN 60745-1 and CEI
EN 60745-2-8) [ dB ]
98
No-load operator Lpa (CEI EN 60745-1 and CEI EN 60745-2-8)
[ dB ]
87
Vibrations when bending Ø 32 mm rod (CEI EN 60745-1 and EN
ISO 5349)
4.01 m/s²
Input voltage [ V ]
230
Frequency [ Hz ]
50
Electrical power [ W ]
1100
Input current [A]
5.3
Insulation class
II
RPM
10000
