- 26 -
ENGLISH
CHARACTERISTICS
ELECTRICAL CHARACTERISTICS
Power supply 230 Vac +/- 10% 50 Hz
Average power consumption 120 W
Power consumption during ignition 320 W
Protection on electronic circuit board Fusibile 2AT, 250 Vac 5x20
N.B.
1) keep in mind that external devices can cause interference to the operation of the circuit board.
2) warning: activity on live components, maintenance and/or checks must be carried out by qualifi ed personnel.
(before carrying out any maintenance, disconnect the appliance from the mains electricity)
The above data are indicative and are those resulting during certifi cation on the part of the notifi ed body.
EDILKAMIN s.p.a. reserves the right to change the products at its discretion without notice.
THERMO TECHNICAL CHARACTERISTICS according to EN 14785
Nominal power Reduced power
Heat input (burnt) 9 2,8 kW
Heat output 8 2,5 kW
Yield / Effi ciency 91,5 92,5 %
Emissions CO 13% O
2
0,013 0,051 %
Fume temperature 133 80 °C
Fuel consumption 1,8 0,6 kg/h
Minimum draught 12 - 5 10 - 3 Pa
Hopper capacity 15 kg
Autonomy 7 20 hours
Heatable volume * 210 m
3
Smoke outlet pipe diameter (male) 80 mm
Air intake pipe diameter (male) 40 mm
Weight including packaging 138 kg
TECHNICAL DATA FOR THE DIMENSIONING OF THE FLUE
Nominal power Reduced power
Heat output 8 2,5 kW
Temperature of fumes on exit from the discharge pipe 160 96 °C
Minimum draught 0 - 5 Pa
Fume fl ow capacity 5,7 3,2 g/s
* The heatable room dimensions are calculated on the basis of home insulation in compliance with Italian law 10/91, and subse-
quent changes together with an expected heat output of 33 Kcal/m³ per hour.
