Edimax BR-6428nS V4 User Manual

96
III-3-8-5. IGMP
IGMP is a communications protocol used to establish multicast group
memberships. It allows for a more efficient use of resources and better
performance for applications such as IPTV video streaming.
IGMP Snooping
IGMP snooping monitors traffic between
hosts and multicast routers to facilitate
bandwidth conservation. Select enable or
disable.
IGMP Proxy
IGMP proxy enables intelligent multicast
forwarding based on IGMP snooping
information. Select enable or disable.
It is recommended to set “IGMP Snooping” and “IGMP Proxy” to
“Enable”.

Edimax BR-6428nS V4 Specifications

General

WPS push button	Yes
Security algorithms	64-bit WEP, 128-bit WEP, IPSEC, SSID, WPA-PSK, WPA2-PSK
Certification	CE, FCC
USB port	No
Ethernet LAN (RJ-45) ports	5
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11b(11Mbps): ‐85±2dBm 11g (54Mbps): ‐68±2dBm 11n(20MHz, MCS7): ‐68±2dBm 11n(40MHz, MCS7): ‐68±2dBm
Ethernet LAN data rates	100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	Power, WAN, WLAN, WPS
Transmit power	18 dBmW
Antennas quantity	2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Output current	1 A
Output voltage	5 V
Power source type	AC
Cables included	DC, LAN (RJ-45)
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s

Weight and Dimensions

Depth	88 mm
Width	145 mm
Height	24 mm
Weight	140 g
