Edimax BR-6428nS V4 User Manual

101
III-3-9-4. Backup/Restore
Backup Settings
Click “Save” to save the current settings on your
computer as config.bin file.
Restore Settings
Click “Browse” to find a previously saved
config.bin file and then click “Upload” to replace
your current settings.
Restore to
Factory Default
Click “Reset” to restore settings to the factory
default. A pop-up window will appear and ask
you to confirm and enter your log in details.
Enter your username and password and click
“Ok”. See below for more information.
III-3-9-5. Upgrade
The upgrade page allows you to upgrade the system firmware to a more
recent version. You can download the latest firmware from the Edimax
website. After the upgrade, the system will restart.
Do not switch off or disconnect the device during a firmware
upgrade, as this could damage the device. It is recommended that
you use a wired Ethernet connection for a firmware upgrade.

Edimax BR-6428nS V4 Specifications

General

WPS push button	Yes
Security algorithms	64-bit WEP, 128-bit WEP, IPSEC, SSID, WPA-PSK, WPA2-PSK
Certification	CE, FCC
USB port	No
Ethernet LAN (RJ-45) ports	5
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11b(11Mbps): ‐85±2dBm 11g (54Mbps): ‐68±2dBm 11n(20MHz, MCS7): ‐68±2dBm 11n(40MHz, MCS7): ‐68±2dBm
Ethernet LAN data rates	100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	Power, WAN, WLAN, WPS
Transmit power	18 dBmW
Antennas quantity	2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Output current	1 A
Output voltage	5 V
Power source type	AC
Cables included	DC, LAN (RJ-45)
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s

Weight and Dimensions

Depth	88 mm
Width	145 mm
Height	24 mm
Weight	140 g
