Select the network authentication type from
drop-down menu. This setting must be identical
with the setting of wireless access point you with
to connect.
Select the data encryption type from drop-down
menu. This setting must be identical with the
setting of wireless access point you with to
connect.
When the encryption type is „WEP‟, it‟s required
to input a set of „passphrase‟ to connect to
wireless access point. Check „ASCII‟ or
„PASSPHRASE‟ depends on the security setting
of access point, and input it in the box; if you
select „PASSPHRASE‟ you also need to select
the length of the key.
The passphrase must be identical with the setting
of wireless access point you with to connect.
Select WEP key index. For most of access points
you can select „1‟, but please refer to the setting
of the access point.
Network key / Confirm
network key
When the encryption type is „WPA‟ or
„WPA2-PSK‟, it‟s required to input a set of
„passphrase‟ to connect to wireless access point.
Please input the same passphrase in two boxes
for confirmation.
EAP TYPE / Tunnel /
Provision Mode
When authentication type is any of 802.1X, you
have to select EAP type, tunnel, and provision
mode from dropdown menu. This setting must be
identical with your 802.1x authentication server.
Username / Identity /
Domain / Password
Please input 802.1x related authentication
information here.
If certification is required to authenticate with
802.1x authentication server, please select a
local certificate from dropdown list.
Check this box and PAC (Privilege Access
Certificate) will be automatically selected.
Please click „OK‟ when ready.
Network card will attempt to connect to access point now, this may require few
seconds to minutes, please be patient. When the „Status‟ become „Associated‟,
your computer is connected to access point you selected. Click „Close‟ to close
configuration menu.
